OEM SUR-RON LB Replacement Motor with Hall Sensor

EBMX XUB-80 SurRon Ultra Bee Motor

EBMX Xtreme Electric Mods combine strenuous in-house R&D and collaborations with industry experts to bring you the ultimate Electric Motor.

The XUB-80 Motor has been purpose built with dirt bike riders in mind.



Slightly bigger with an 80mm Stator thickness and more powerful than its little brother the XLB-60.

40KW rated & designed from the ground up to handle the heat, 180C rated windings with U42H magnets.

Custom IPM rotor design and industry leading 1mm rotor air gap revving out to rated 12000RPM.

Encoder based motor control for increased low end torque response and smooth predicable power delivery.

We built these motors to stay cool under race conditions to ensure you focus on your riding and not your motor temperatures. It doesn’t matter if you are on the track, street or local trail, if you want the best, then this motor is for you.

The EBMX motor range has been specifically designed to surpass the performance of other motors in their classes.

EBMX motor have been custom built and are finely tuned to work with the EBMX X-9000 controller. These motors will work with many other types of controllers, however they may require you to do your own custom tuning

Custom IPM rotor design and industry leading 1mm rotor air gap revving out to rated 13000RPM. Encoder based motor control for increased low end torque response and smooth predicable power delivery.

We built this motor to perform back to back, if your on the track, street or local trail, if you want the best, then this motor is for you.

The EBMX motor range has been specifically designed to surpass the performance of other motors in their classes.

In contrast to many of our competitors who utilize hall sensors, we have opted to incorporate encoder sensors in our motors. This decision stems from the fact that encoder sensors demonstrate greater stability under demanding riding conditions. While hall sensors rely on estimated rotor positions, encoder sensors consistently provide precise angle measurements of the rotor’s position. Hall sensors are typically employed for tracking motor position during start-up and up to approximately 2000 rpm, after which the motor operates in a “sensorless” manner. However, during intense riding situations such as wheel spinning and sudden deceleration combined with rapid throttle adjustments, hall sensors angle detection can result in substantial current spikes in the controller. This can pose significant issues for many controllers, leading to tripping and loss of throttle power, although this is less prevalent in the X-9000.

Encoder sensors, on the other hand, are capable of tracking motor position at all speeds and do so more frequently than hall sensors. As a result, they offer a more responsive motor experience and enhance performance reliability and durability. Furthermore, they contribute to improved low-end torque control and overall motor response.

EBMX XUB-80 SurRon Ultra Bee Motor

EBMX Xtreme Electric Mods combine strenuous in-house R&D and collaborations with industry experts to bring you the ultimate Electric Motor.

The XUB-80 Motor has been purpose built with dirt bike riders in mind.

Slightly bigger with an 80mm Stator thickness and more powerful than its little brother the XLB-60.

40KW rated & designed from the ground up to handle the heat, 180C rated windings with U42H magnets.

Custom IPM rotor design and industry leading 1mm rotor air gap revving out to rated 12000RPM.

Encoder based motor control for increased low end torque response and smooth predicable power delivery.

We built these motors to stay cool under race conditions to ensure you focus on your riding and not your motor temperatures. It doesn’t matter if you are on the track, street or local trail, if you want the best, then this motor is for you.

The EBMX motor range has been specifically designed to surpass the performance of other motors in their classes.

EBMX motor have been custom built and are finely tuned to work with the EBMX X-9000 controller. These motors will work with many other types of controllers, however they may require you to do your own custom tuning

Custom IPM rotor design and industry leading 1mm rotor air gap revving out to rated 13000RPM. Encoder based motor control for increased low end torque response and smooth predicable power delivery.

We built this motor to perform back to back, if your on the track, street or local trail, if you want the best, then this motor is for you.

The EBMX motor range has been specifically designed to surpass the performance of other motors in their classes.

In contrast to many of our competitors who utilize hall sensors, we have opted to incorporate encoder sensors in our motors. This decision stems from the fact that encoder sensors demonstrate greater stability under demanding riding conditions. While hall sensors rely on estimated rotor positions, encoder sensors consistently provide precise angle measurements of the rotor’s position. Hall sensors are typically employed for tracking motor position during start-up and up to approximately 2000 rpm, after which the motor operates in a “sensorless” manner. However, during intense riding situations such as wheel spinning and sudden deceleration combined with rapid throttle adjustments, hall sensors angle detection can result in substantial current spikes in the controller. This can pose significant issues for many controllers, leading to tripping and loss of throttle power, although this is less prevalent in the X-9000.

Encoder sensors, on the other hand, are capable of tracking motor position at all speeds and do so more frequently than hall sensors. As a result, they offer a more responsive motor experience and enhance performance reliability and durability. Furthermore, they contribute to improved low-end torque control and overall motor response.

EBMX XLB-60 SurRon Light Bee Motor

EBMX Xtreme Electric Mods combine strenuous in-house R&D and collaborations with industry experts to bring you the ultimate Electric Motor.

The XLB-60 Motor has been purpose built with dirt bike riders in mind.



35KW rated and tested, designed from the ground up to handle the heat, 180C rated windings with U42H magnets

Custom IPM rotor design and industry leading 1mm rotor air gap revving out to rated 13000RPM. Encoder based motor control for increased low end torque response and smooth predicable power delivery.

We built this motor to perform back to back, if your on the track, street or local trail, if you want the best, then this motor is for you.

The EBMX motor range has been specifically designed to surpass the performance of other motors in their classes.

In contrast to many of our competitors who utilize hall sensors, we have opted to incorporate encoder sensors in our motors. This decision stems from the fact that encoder sensors demonstrate greater stability under demanding riding conditions. While hall sensors rely on estimated rotor positions, encoder sensors consistently provide precise angle measurements of the rotor’s position. Hall sensors are typically employed for tracking motor position during start-up and up to approximately 2000 rpm, after which the motor operates in a “sensorless” manner. However, during intense riding situations such as wheel spinning and sudden deceleration combined with rapid throttle adjustments, hall sensors angle detection can result in substantial current spikes in the controller. This can pose significant issues for many controllers, leading to tripping and loss of throttle power, although this is less prevalent in the X-9000.

Encoder sensors, on the other hand, are capable of tracking motor position at all speeds and do so more frequently than hall sensors. As a result, they offer a more responsive motor experience and enhance performance reliability and durability. Furthermore, they contribute to improved low-end torque control and overall motor response.

A EBMX Motor Bash Guard is included with each purchase of your EBMX XLB-60 Motor. This cleverly designed simple guard will protect both the OEM Surron Light bee Motor and the EBMX upgraded XLB-60 Motor. Bolts on far easier than the SXS type and offers a custom befit protection for the XLB-60 not found on other guards.

EBMX XLB-60 SurRon Light Bee Motor

EBMX Xtreme Electric Mods combine strenuous in-house R&D and collaborations with industry experts to bring you the ultimate Electric Motor.

The XLB-60 Motor has been purpose built with dirt bike riders in mind.



35KW rated and tested, designed from the ground up to handle the heat, 180C rated windings with U42H magnets

Custom IPM rotor design and industry leading 1mm rotor air gap revving out to rated 13000RPM. Encoder based motor control for increased low end torque response and smooth predicable power delivery.

We built this motor to perform back to back, if your on the track, street or local trail, if you want the best, then this motor is for you.

The EBMX motor range has been specifically designed to surpass the performance of other motors in their classes.

In contrast to many of our competitors who utilize hall sensors, we have opted to incorporate encoder sensors in our motors. This decision stems from the fact that encoder sensors demonstrate greater stability under demanding riding conditions. While hall sensors rely on estimated rotor positions, encoder sensors consistently provide precise angle measurements of the rotor’s position. Hall sensors are typically employed for tracking motor position during start-up and up to approximately 2000 rpm, after which the motor operates in a “sensorless” manner. However, during intense riding situations such as wheel spinning and sudden deceleration combined with rapid throttle adjustments, hall sensors angle detection can result in substantial current spikes in the controller. This can pose significant issues for many controllers, leading to tripping and loss of throttle power, although this is less prevalent in the X-9000.

Encoder sensors, on the other hand, are capable of tracking motor position at all speeds and do so more frequently than hall sensors. As a result, they offer a more responsive motor experience and enhance performance reliability and durability. Furthermore, they contribute to improved low-end torque control and overall motor response.

A EBMX Motor Bash Guard is included with each purchase of your EBMX XLB-60 Motor. This cleverly designed simple guard will protect both the OEM Surron Light bee Motor and the EBMX upgraded XLB-60 Motor. Bolts on far easier than the SXS type and offers a custom befit protection for the XLB-60 not found on other guards.
